Product description:

YE3 series CDL stainless steel vertical multi-stage pump special motor, is developed as a new design of our company based on the characteristics of CDL stainless steel vertical multi-stage pump.This motors with unique appearance, IP55 protection class, F insulation class, and a good function of energy saving can reach high efficiency class in line with international standard IE2 and Chinese standard efficiency class 3, which has made it an ideal energy saving product.Moreover, it has other good features like high starting torque, slight noise, low vibration, optimum structure, convenient operation and so on.
In order to solve problems like high torque, low vibration, slight noise in pumps, we use cast iron material for all front flange and rear end shield in our new motors, and this improvement can completely meet the application of various types of pumps.

Conditions of Use:

Ambient temperature:-15℃≤0≤40℃
Altitude:Not exceeding 1000m
Rated Voltage:380V 400V 415V
Rated frequency:50HZ 60HZ
Connection:Star-connection for 3KW or less whereas delta connection for 4KW or more
Duty:Continuous(S1)
Insulation Class:Class F
Protection Class:The main body of the motor is IP54、IP55 but the terminal box reaches IP55
Cooling Type:IC411
